Vanch smart UHF RFID antenna Asset tracking for shelf

FOB Reference Price:Get Latest Price
US $45-50 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Vanch
Model Number:
VA-9122
Model:
VA-9122H
Brand:
Vanch
Frequency:
865-868MHz; 902-928 MHz (can be customized)
Input Impedance:
50 Ohm load
Antenna connector:
SMA antennas connector or can be customized
Gain-dBi:
12dBi
Polarization:
Linear polarization
Dimension:
840(L)*100(W)*30(H)mm
Weight:
0.9KG
Keyword:
shelf uhf rfid antenna
Supply Ability
Supply Ability:
100 Set/Sets per Day
Packaging & Delivery
Packaging Details
Packing Detail: packing in carton box
Port
Shenzhen
Lead Time :
1-7 days shipping after payment

Vanch smart UHF RFID antenn Asset tracking for shelf



Introduction:



This antenna has ultra-thin design, mounting convenience

It is ideal choice to be specifically applicable to the asset management smart shelves, RFID antennas and file Shelves.



Features:

1. Antenna gain has 10dbi and 12 dBi options

2. Working frequency is between 865-868MHz; 902-928 MHz (can be customized)

3. With SMA and MCX antenna connector options

4. Anti-jamming, waterproof and dustproof capabilities can meet requirement of harsh work environment.



Specification:

Specification



Model

VA-9122H



Performance Index

Frequency

865-868MHz; 902-928 MHz (can be customized)

Input Impedance

50 Ohm load

Antenna connector

SMA antennas connector or can be customized.

Gain-dBi

12dBi

VSWR

≤1.3

Polarization

Linear polarization

E direction wave beam width -°

120

H direction wave beam width -°

30

Dimension

840(L)*100(W)*30(H)mm

Weight

0.9KG

About us:

QQ20170324152211.jpgQQ20170324152330.jpgQQ20170324152349.jpgabout us.pngcertification.jpgdelivery.jpgfactory.png
